40 mm Milling Burs for vhf E4/E5/K5/K5+/S5/R5 | 3 mm Shank

OnePro Dental replacement milling burs with a 3 mm shank and 40 mm overall length for selected vhf E4, E5, K5, K5+, S5 and R5 setups. Choose a diamond-coated zirconia or uncoated PMMA & Wax option according to your CAM tool library. Confirm the tip profile and stop-ring position against your current bur before ordering.

Regular price $13.90
Sale price $13.90 Regular price $17.90
Shipping calculated at checkout.

Price per bur. Select your required tool model before adding to cart.

Tool Option

Zirconia options are diamond-coated; PMMA & Wax options are uncoated. All burs have a 3 mm shank and 40 mm overall length.

  • Secure PayPal Checkout
  • Tool Selection Support
  • Worldwide Shipping Available

Choose by Material & Machine

Tool range Available profiles Coating Machine reference
Zirconia Ø0.6 / 1.0 / 2.0 mm round; Ø1.2 mm flat-end Diamond-coated cutting section Selected vhf E4, E5, K5, K5+, S5 and R5 setups
PMMA & Wax Ø0.6 / 1.0 / 2.0 mm round Uncoated cutting section Selected vhf E4, E5, K5, K5+, S5 and R5 setups

Machine models are references only. Confirm that your machine setup accepts a 3 mm shank and 40 mm overall tool length, then compare the stop-ring position and CAM tool profile with your current bur.

E4/E5 roughing programs that specify an AIRTOOL require a dedicated AIRTOOL; the standard burs on this page do not replace it.

Technical Specifications

Specification Value
Shank diameter 3 mm
Overall tool length 40 mm
Available materials Zirconia; PMMA and wax
Zirconia coating Diamond-coated cutting section
PMMA & wax coating Uncoated
Cutting profiles Round and flat-end, depending on selected option
Stop ring Present; confirm its seating position against your current tool
Quantity supplied The selected tool option and quantity

How to Select Your Bur

  • Match the Material

    Choose a diamond-coated bur for zirconia or an uncoated bur for PMMA and wax. Select the cutting diameter and tip profile required by your CAM program.

  • Check the Tool Reference

    Compare the cutting diameter, tip and neck geometry, 3 mm shank, 40 mm overall length and stop-ring position with your current bur and CAM tool profile.

  • Confirm the Machine Setup

    Check your specific vhf E4, E5, K5, K5+, S5 or R5 configuration and its CAM tool library. For E4/E5 roughing stages that specify an AIRTOOL, use the dedicated AIRTOOL.

1 of 3

FAQ

Does the order include all seven burs shown?

No. The images show the available range. Your order includes only the selected tool option and quantity.

Are these original vhf tools?

No. These are replacement tools supplied by OnePro Dental. They are not manufactured by or affiliated with vhf.

Can these tools replace an E4 or E5 AIRTOOL?

No. If your CAM program requires an AIRTOOL for roughing, order the specified AIRTOOL separately.

Can I use these burs for metal or glass ceramic?

No. The options on this page are for zirconia or PMMA and wax, as indicated by the selected tool option.

What should I check before ordering?

Confirm the material, cutting diameter, tip profile, 3 mm shank, 40 mm overall length, stop-ring position and CAM tool assignment.

Explore More VHF Milling Burs

Looking for another shank size, overall length or material? Browse our VHF-compatible milling bur collection and compare each product’s machine reference and tool specifications.
